H05V2-K / H07V2-K CABLES
CABLE DESCRIPTION
Flexible single core PVC insulated electric cables, sheathless, for internal wiring and for general use, with continuous operating temperature of 90°c.
CABLE CONSTRUCTION
1 – Flexible copper class 5 CEI EN 60228
2 – PVC TI3
STANDARDS
CEI 20-20/7
HD 21
EN 50525-2-31
CHARECTERISTICS
Operating Temp: +50C ~ +900C on the conductor
Rated Voltage : - H05V2-K: Uo/U 300/500 V
- H07V2-K: Uo/U 450/750 V
Max. Short Circuit temp: +160°C (For 5 Seconds)
Min. Bending Radius: Fixed Installation – 4x outer Diameter
You can Download the datasheet from the below link
H07V2-K.pdf
